NEMA Pushbutton, 12 (304 STAINLESS STEEL) JIC 30MM PUSHBUTTON EXTRA LARGE ENCLOSURE WITH SCREW COVER - SERIES JS12SLPB30

NEMA Pushbutton, 12 (304 STAINLESS STEEL) JIC 30MM PUSHBUTTON EXTRA LARGE ENCLOSURE WITH SCREW COVER

SERIES JS12SLPB30

• Suitable for use as an electrical junction box, terminal box, and instrument housing
• Conveniently pre-cut to accomodate installation of 30.5 mm pilot devices in cover
• Depth allows for additional pilot device contact blocks
• Larger design includes sub panel to allow for installation of additional components
• Removable cover allows for easy access to internal components
• Designed for indoor use and will protect components from falling dust, dirt, oil and water

• NEMA Type Pushbutton, 12
• CSA Type Pushbutton, 12
• UL Type Pushbutton, 12

• Fabricated from 16 or 14 gauge type 304 stainless steel with seam welds that are ground smooth
• Door is secured with captive machine screws
• Includes a removable 14 gauge type 304 stainless steel sub plate
• Door gasket is seamless foam-in-place polyurethane
• Ground studs are included on both the door and enclosure body
• Mounting feet are formed from enclosure body, reducing potential corrosion
• Enclosure is polished to a #4 finish
• Sub plate is finished in white polyester powder coating over a phosphated surface

———————
• CSA File: 111860
• UL File: E304861

JS12SLPB30.pdf

JS12SLPB30

Type 12

Family Pushbutton
